Espa2-7 pure water low pressure reverse osmosis membrane

您当前位置:贴标机首页 > Adhesive backing machine > FPC adhesive backing machine

Espa2-7 pure water low pressure reverse osmosis membrane

  • 产品名称:Espa2-7 pure water low pressure reverse osmosis membrane
  • 产品分类:Adhesive backing machine
  • 浏览次数:177704次
  • 更新时间:2019/8/14 17:38:41
  • 咨询热线:133-6065-4218

ESPA2 is the diaphragm with the highest desalination rate in ESPA series. Different types of products are made by rolling this diaphragm, which has the characteristics of high desalination rate and better energy saving effect. ESPA2 comes in 4 "and 8" sizes.

The membrane area of espa2-7 membrane element is 400 ft2 (37.2m2), and the membrane quantity can be saved by about 10% when using the same water flux design. Espa2-7 is commonly used in ultra-pure water systems or secondary RO systems. Espa2-7 is an 8-inch membrane element.

Espa2-7 is a new type of membrane element which adopts the innovative diaphragm technology of headneng company and combines the large membrane area and the wide water inlet barrier network 34mil. At the same time, it has the characteristics of large membrane area reducing the use of membrane, and has anti-pollution and blocking performance, suitable for large municipal, semiconductor industry and other applications


I. performance parameters of espa2-7 Hyde energy low-pressure pure water film

model

ESPA2-7

specifications

8 inches

performance

Desalination rate

nominal

96%

The minimum

95.6%

Water rate

9000gpd (34.1m3/d)

type

Film material

Aromatic polyamide composites

structure

Roll type

Effective membrane area

400ft²(37.2㎡)

Test condition

solution

1500mg/L NaCl

pressure

75psi(0.52Pa)

The temperature

77°F(25℃)

The recovery rate of

15%

pH

6.5-7.0

Ii. Use and restriction of products:

Maximum operating pressure

600 psig (4.14MPa)

The largest water residual chlorine concentration

<0.1 mg/L

Maximum inlet temperature

113 °F (45 °C)

Operating pH range

2-10.6

Maximum inlet turbidity

1.0 NTU

The largest water SDI15

5.0

Maximum inflow

75gpm (17mm³/h)

Maximum pressure drop for single membrane elements

10psi (0.07MPa)


Iii. Product description:
